Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UHE Series Datasheet
Standard Package	100
Manufacturer	Nichicon
Series	UHE
Packaging	Bulk
Part Status	Active
Capacitance	1000µF
Tolerance	±20%
Voltage - Rated	50V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	10000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	2.19A @ 120Hz
Ripple Current @ High Frequency	2.92A @ 100kHz
Impedance	21 mOhms
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.492" Dia (12.50mm)
Height - Seated (Max)	1.575" (40.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UHE1V182MHD6TN	Nichicon, 1800µF 35V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHE	View
UHE1C102MHD6	Nichicon, 1000µF 16V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHE	View
UHE1V471MPD1TD	Nichicon, 470µF 35V Aluminum Electrolytic Capacitors Radial, Can 7000 Hrs @ 105°C, UHE	View
UHE0J331MED	Nichicon, 330µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 4000 Hrs @ 105°C, UHE	View
UHE0J103MHD6	Nichicon, 10000µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 8000 Hrs @ 105°C, UHE	View
UHE1C222MHD1TO	Nichicon, 2200µF 16V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHE	View
UHE0J183MHD	Nichicon, 18000µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 8000 Hrs @ 105°C, UHE	View
UHE2A181MHD6	Nichicon, 180µF 100V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHE	View
UHE1A101MDD	Nichicon, 100µF 10V Aluminum Electrolytic Capacitors Radial, Can 4000 Hrs @ 105°C, UHE	View
UHE2A150MED1TD	Nichicon, 15µF 100V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UHE	View
UHE1A152MPD1TD	Nichicon, 1500µF 10V Aluminum Electrolytic Capacitors Radial, Can 6000 Hrs @ 105°C, UHE	View
UHE1H331MPD1TD	Nichicon, 330µF 50V Aluminum Electrolytic Capacitors Radial, Can 7000 Hrs @ 105°C, UHE	View

UHE1H102MHD

Part NumberUHE1H102MHD
