Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	ULV Series
Standard Package	500
Manufacturer	Nichicon
Series	ULV
Packaging	Tape & Reel (TR)
Part Status	Active
Capacitance	6.8µF
Tolerance	±20%
Voltage - Rated	400V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	10000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	50mA @ 120Hz
Ripple Current @ High Frequency	80mA @ 10kHz
Lead Spacing	-
Size / Dimension	0.394" Dia (10.00mm)
Height - Seated (Max)	0.433" (11.00mm)
Surface Mount Land Size	0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD

ULV2C330MNL1GS	Nichicon, 33µF 160V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View
ULV2W5R6MNL1GS	Nichicon, 5.6µF 450V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View
ULV2G3R9MNL1GS	Nichicon, 3.9µF 400V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View
ULV2G6R8MNL1GS	Nichicon, 6.8µF 400V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View
ULV2C150MNL1GS	Nichicon, 15µF 160V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View
ULV2H4R7MNL1GS	Nichicon, 4.7µF 500V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View
ULV2W7R5MNL1GS	Nichicon, 7.5µF 450V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View
ULV2C220MNL1GS	Nichicon, 22µF 160V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View
ULV2D120MNL1GS	Nichicon, 12µF 200V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View
ULV2W3R3MNL1GS	Nichicon, 3.3µF 450V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View
ULV2C150MNL1GS	Nichicon, 15µF 160V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View
ULV2E150MNL1GS	Nichicon, 15µF 250V Aluminum Electrolytic Capacitors Radial, Can - SMD 10000 Hrs @ 105°C, ULV	View

ULV2G6R8MNL1GS

Part NumberULV2G6R8MNL1GS
