Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UMA Series
Standard Package	2000
Manufacturer	Nichicon
Series	UMA
Packaging	Tape & Box (TB)
Part Status	Active
Capacitance	10µF
Tolerance	±20%
Voltage - Rated	25V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	2000 Hrs @ 85°C
Operating Temperature	-40°C ~ 85°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	27mA @ 120Hz
Ripple Current @ High Frequency	40.5mA @ 10kHz
Lead Spacing	0.098" (2.50mm)
Size / Dimension	0.197" Dia (5.00mm)
Height - Seated (Max)	0.236" (6.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UMA1E330MDD1TP	Nichicon, 33µF 25V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA0J470MDD1TP	Nichicon, 47µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA0G330MDD1TP	Nichicon, 33µF 4V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1E3R3MCD2	Nichicon, 3.3µF 25V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA0G471MDD1TP	Nichicon, 470µF 4V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1HR22MCD2TP	Nichicon, 0.22µF 50V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1HR22MDD1TP	Nichicon, 0.22µF 50V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1HR47MDD1TP	Nichicon, 0.47µF 50V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA0J470MDD1TP	Nichicon, 47µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1A101MDD1TP	Nichicon, 100µF 10V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA0J221MDD1TP	Nichicon, 220µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA0G220MCD2TP	Nichicon, 22µF 4V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View

UMA1E100MDD1TP

Part NumberUMA1E100MDD1TP
