Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UMF Series
Standard Package	200
Manufacturer	Nichicon
Series	UMF
Packaging	Bulk
Part Status	Active
Capacitance	1µF
Tolerance	±20%
Voltage - Rated	35V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	1000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	25mA @ 120Hz
Ripple Current @ High Frequency	50mA @ 100kHz
Impedance	5 Ohms
Lead Spacing	0.059" (1.50mm)
Size / Dimension	0.157" Dia (4.00mm)
Height - Seated (Max)	0.236" (6.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UMF1V220MDD1TP	Nichicon, 22µF 35V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View
UMF1E330MDD1TP	Nichicon, 33µF 25V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View
UMF1V150MDD1TP	Nichicon, 15µF 35V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View
UMF0J220MDD1TP	Nichicon, 22µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View
UMF0J680MDD1TP	Nichicon, 68µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View
UMF1A330MDD1TP	Nichicon, 33µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View
UMF0J220MDD1TP	Nichicon, 22µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View
UMF1E330MDD	Nichicon, 33µF 25V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View
UMF1V4R7MDD1TP	Nichicon, 4.7µF 35V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View
UMF1V1R5MDD1TP	Nichicon, 1.5µF 35V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View
UMF1V100MDD1TP	Nichicon, 10µF 35V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View
UMF0J101MDD1TP	Nichicon, 100µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UMF	View

UMF1V010MDD

Part NumberUMF1V010MDD
