Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UMV Series
Standard Package	1
Manufacturer	Nichicon
Series	UMV
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	100µF
Tolerance	±20%
Voltage - Rated	4V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	5000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	60mA @ 120Hz
Ripple Current @ High Frequency	90mA @ 10kHz
Lead Spacing	0.098" (2.50mm)
Size / Dimension	0.248" Dia (6.30mm)
Height - Seated (Max)	0.236" (6.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UMV1E100MFD1TP	Nichicon, 10µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1H100MFD	Nichicon, 10µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1H010MFD1TP	Nichicon, 1µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV0J470MFD1TP	Nichicon, 47µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1A330MFD1TP	Nichicon, 33µF 10V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1E100MFD1TP	Nichicon, 10µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1V220MFD1TP	Nichicon, 22µF 35V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1A470MFD	Nichicon, 47µF 10V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1HR47MFD1TP	Nichicon, 0.47µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1A330MFD1TP	Nichicon, 33µF 10V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1HR22MFD1TP	Nichicon, 0.22µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1E220MFD1TP	Nichicon, 22µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View

UMV0G101MFD1TP

Part NumberUMV0G101MFD1TP
