Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UPV Series
Standard Package	1
Manufacturer	Nichicon
Series	UPV
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	47µF
Tolerance	±20%
Voltage - Rated	35V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	5000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Polarization	-
Ratings	-
Applications	General Purpose
Impedance	580 mOhms
Lead Spacing	0.098" (2.50mm)
Size / Dimension	0.248" Dia (6.30mm)
Height - Seated (Max)	0.492" (12.50mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UPV1A151MGD1TD	Nichicon, 150µF 10V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1C820MGD1TD	Nichicon, 82µF 16V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1H010MFD1TD	Nichicon, 1µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1H150MFD1TD	Nichicon, 15µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1E330MFD1TD	Nichicon, 33µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1H6R8MFD1TD	Nichicon, 6.8µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1H1R5MFD1TD	Nichicon, 1.5µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1A101MGD1TD	Nichicon, 100µF 10V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1E101MGD1TD	Nichicon, 100µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1A271MGD1TD	Nichicon, 270µF 10V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1E330MFD	Nichicon, 33µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1V680MGD1TD	Nichicon, 68µF 35V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View

UPV1V470MGD1TD

Part NumberUPV1V470MGD1TD
