Categories	Capacitors / Ceramic Capacitors
Datasheet	UQCA,CB,CR Series
Standard Package	1
Manufacturer	AVX Corporation
Series	UQ
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	1.8pF
Tolerance	±0.1pF
Voltage - Rated	200V
Temperature Coefficient	A
Operating Temperature	-55°C ~ 125°C
Features	High Q, Low Loss
Ratings	-
Applications	RF, Microwave, High Frequency
Mounting Type	Surface Mount, MLCC
Package / Case	0402 (1005 Metric)
Size / Dimension	0.040" L x 0.020" W (1.02mm x 0.51mm)
Height - Seated (Max)	-
Thickness (Max)	0.024" (0.60mm)
Lead Spacing	-
Lead Style	-

UQCSVA3R9CAT2A\500	AVX Corporation, 3.9pF ±0.25pF 250V Ceramic Capacitor A 0603 (1608 Metric), UQ	View
UQCSVA3R0BAT2A\500	AVX Corporation, 3pF ±0.1pF 250V Ceramic Capacitor A 0603 (1608 Metric), UQ	View
UQCL2A120JAT2A\500	AVX Corporation, 12pF ±5% 200V Ceramic Capacitor A 0402 (1005 Metric), UQ	View
UQCSVA8R2CAT2A\500	AVX Corporation, 8.2pF ±0.25pF 250V Ceramic Capacitor A 0603 (1608 Metric), UQ	View
UQCFVA1R8BAT2A\500	AVX Corporation, 1.8pF ±0.1pF 250V Ceramic Capacitor A 0805 (2012 Metric), UQ	View
UQCFVA120JAT2A\500	AVX Corporation, 12pF ±5% 250V Ceramic Capacitor A 0805 (2012 Metric), UQ	View
UQCL2A2R2BAT2A\500	AVX Corporation, 2.2pF ±0.1pF 200V Ceramic Capacitor A 0402 (1005 Metric), UQ	View
UQCSVA0R1BAT2A\500	AVX Corporation, 0.1pF ±0.1pF 250V Ceramic Capacitor A 0603 (1608 Metric), UQ	View
UQCL2A0R9BAT2A\500	AVX Corporation, 0.9pF ±0.1pF 200V Ceramic Capacitor A 0402 (1005 Metric), UQ	View
UQCFVA0R4BAT2A\500	AVX Corporation, 0.4pF ±0.1pF 250V Ceramic Capacitor A 0805 (2012 Metric), UQ	View
UQCFVA3R0BAT2A\500	AVX Corporation, 3pF ±0.1pF 250V Ceramic Capacitor A 0805 (2012 Metric), UQ	View
UQCSVA330JAT2A\500	AVX Corporation, 33pF ±5% 250V Ceramic Capacitor A 0603 (1608 Metric), UQ	View

UQCL2A1R8BAT2A/500

Part NumberUQCL2A1R8BAT2A\500
