Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	URY Series
Standard Package	1
Manufacturer	Nichicon
Series	URY
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	100µF
Tolerance	±20%
Voltage - Rated	100V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	230mA @ 120Hz
Ripple Current @ High Frequency	345mA @ 10kHz
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.492" Dia (12.50mm)
Height - Seated (Max)	0.551" (14.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

URY2C330MHD1TO	Nichicon, 33µF 160V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View
URY2E470MRD	Nichicon, 47µF 250V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View
URY2F470MRD	Nichicon, 47µF 315V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View
URY1E681MHD	Nichicon, 680µF 25V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View
URY1V681MHD	Nichicon, 680µF 35V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View
URY1E681MHD1TO	Nichicon, 680µF 25V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View
URY2G220MRD	Nichicon, 22µF 400V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View
URY2D220MHD1TO	Nichicon, 22µF 200V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View
URY2C330MHD1TO	Nichicon, 33µF 160V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View
URY1J221MHD1TO	Nichicon, 220µF 63V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View
URY1C222MRD	Nichicon, 2200µF 16V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View
URY2F100MHD1TO	Nichicon, 10µF 315V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, URY	View

URY2A101MHD1TO

Part NumberURY2A101MHD1TO
