UT2024-006

Part NumberUT2024-006

ManufacturerTriad Magnetics

DescriptionCOMMON MODE CHOKE 500MA 2LN TH

DatasheetUT2024-006 Datasheet

Package / CaseHorizontal, 4 PC Pin

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description9mH @ 10kHz 2 Line Common Mode Choke Through Hole 500mA DCR 1.4Ohm

To learn about the specification of UT2024-006, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add UT2024-006 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of UT2024-006.
We are offering UT2024-006 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

UT2024-006 - Product Attributes

Categories

Filters / Common Mode Chokes

Datasheet

UT2024-006 Datasheet

Standard Package

Manufacturer

Triad Magnetics

Series

Packaging

Bulk

Part Status

Active

Filter Type

Power Line

Number of Lines

Inductance @ Frequency

9mH @ 10kHz

Current Rating (Max)

500mA

DC Resistance (DCR) (Max)

1.4Ohm

Voltage Rating - DC

Voltage Rating - AC

250V

Operating Temperature

-20°C ~ 105°C

Ratings

Approvals

CSA, IEC, UL

Features

ESD

Mounting Type

Through Hole

Size / Dimension

0.728" L x 0.905" W (18.49mm x 22.99mm)

Height (Max)

0.925" (23.50mm)

Package / Case

Horizontal, 4 PC Pin
