Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UUG Series
Standard Package	70
Manufacturer	Nichicon
Series	UUG
Packaging	Tray
Part Status	Active
Capacitance	100µF
Tolerance	±20%
Voltage - Rated	63V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	2000 Hrs @ 85°C
Operating Temperature	-40°C ~ 85°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	370mA @ 120Hz
Ripple Current @ High Frequency	555mA @ 10kHz
Lead Spacing	-
Size / Dimension	0.492" Dia (12.50mm)
Height - Seated (Max)	0.571" (14.50mm)
Surface Mount Land Size	0.535" L x 0.535" W (13.60mm x 13.60mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD

UUG0J472MNQ1MS	Nichicon, 4700µF 6.3V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View
UUG1V102MNQ6MS	Nichicon, 1000µF 35V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View
UUG1C102MNQ1ZD	Nichicon, 1000µF 16V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View
UUG1V102MNQ1MS	Nichicon, 1000µF 35V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View
UUG1V471MNQ1MS	Nichicon, 470µF 35V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View
UUG1C102MNQ1MS	Nichicon, 1000µF 16V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View
UUG1A472MNQ6MS	Nichicon, 4700µF 10V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View
UUG1V102MNQ1MS	Nichicon, 1000µF 35V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View
UUG1A682MNQ1MS	Nichicon, 6800µF 10V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View
UUG0J472MNQ1MS	Nichicon, 4700µF 6.3V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View
UUG2G220MNQ6MS	Nichicon, 22µF 400V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View
UUG1A472MNQ1MS	Nichicon, 4700µF 10V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85°C, UUG	View

UUG1J101MNQ1ZD

Part NumberUUG1J101MNQ1ZD
