Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UVZ Series
Standard Package	1
Manufacturer	Nichicon
Series	UVZ
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	330µF
Tolerance	±20%
Voltage - Rated	25V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	1000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	315mA @ 120Hz
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.394" Dia (10.00mm)
Height - Seated (Max)	0.551" (14.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UVZ2A100MED	Nichicon, 10µF 100V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2C101MHD1TO	Nichicon, 100µF 160V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1H2R2MDD1TA	Nichicon, 2.2µF 50V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1V101MED1TD	Nichicon, 100µF 35V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1A220MDD1TD	Nichicon, 22µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1V331MPD1TD	Nichicon, 330µF 35V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2AR33MDD	Nichicon, 0.33µF 100V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2CR47MED1TD	Nichicon, 0.47µF 160V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1C331MPD1TD	Nichicon, 330µF 16V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2E100MPD1TD	Nichicon, 10µF 250V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1C101MDD1TA	Nichicon, 100µF 16V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ0J103MHD1TN	Nichicon, 10000µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View

UVZ1E331MPD1TD

Part NumberUVZ1E331MPD1TD
