VLS5045EX-150M


VLS5045EX-150M

Part NumberVLS5045EX-150M

Manufacturer

Description

Datasheet

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

VLS5045EX-150M - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package1500
ManufacturerTDK Corporation
SeriesVLS-EX
PackagingTape & Reel (TR)
Part StatusActive
TypeWirewound
Material - CoreFerrite
Inductance15µH
Tolerance±20%
Current Rating (Amps)1.9A
Current - Saturation2.2A
ShieldingShielded
DC Resistance (DCR)143mOhm Max
Q @ Freq-
Frequency - Self Resonant-
Ratings-
Operating Temperature-40°C ~ 105°C
Inductance Frequency - Test100kHz
Mounting TypeSurface Mount
Package / CaseNonstandard
Supplier Device Package-
Size / Dimension0.197" L x 0.197" W (5.00mm x 5.00mm)
Height - Seated (Max)0.177" (4.50mm)
