VS-E4PH3006L-N3

VS-E4PH3006L-N3

Part NumberVS-E4PH3006L-N3

ManufacturerVishay Semiconductor Diodes Division

DescriptionDIODE GEN PURP 600V 30A TO247AD

DatasheetVS-E4PH3006L-N3

Package / CaseTO-247-2

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionDiode Standard 600V 30A Through Hole TO-247AD

To learn about the specification of VS-E4PH3006L-N3, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add VS-E4PH3006L-N3 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of VS-E4PH3006L-N3.
We are offering VS-E4PH3006L-N3 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

VS-E4PH3006L-N3 - Product Attributes

Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	VS-E4PH3006L-N3
Standard Package	25
Manufacturer	Vishay Semiconductor Diodes Division
Series	FRED Pt®
Packaging	Tube
Part Status	Active
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	600V
Current - Average Rectified (Io)	30A
Voltage - Forward (Vf) (Max) @ If	2V @ 30A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)	55ns
Current - Reverse Leakage @ Vr	50µA @ 600V
Capacitance @ Vr, F	-
Mounting Type	Through Hole
Package / Case	TO-247-2
Supplier Device Package	TO-247AD
Operating Temperature - Junction	-55°C ~ 175°C
