ZXTD720MCTA

Part NumberZXTD720MCTA

ManufacturerDiodes Incorporated

DescriptionTRANS 2PNP 40V 3A 8DFN

DatasheetZXTD720MC

Package / Case8-WDFN Exposed Pad

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor Array 2 PNP (Dual) 40V 3A 190MHz 1.7W Surface Mount 8-DFN (3x2)

To learn about the specification of ZXTD720MCTA, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add ZXTD720MCTA with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of ZXTD720MCTA.
We are offering ZXTD720MCTA for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

ZXTD720MCTA - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Arrays
Datasheet	ZXTD720MC
Standard Package	3000
Manufacturer	Diodes Incorporated
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Transistor Type	2 PNP (Dual)
Current - Collector (Ic) (Max)	3A
Voltage - Collector Emitter Breakdown (Max)	40V
Vce Saturation (Max) @ Ib, Ic	370mV @ 250mA, 2.5A
Current - Collector Cutoff (Max)	100nA
DC Current Gain (hFE) (Min) @ Ic, Vce	60 @ 1.5A, 2V
Power - Max	1.7W
Frequency - Transition	190MHz
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	8-WDFN Exposed Pad
Supplier Device Package	8-DFN (3x2)
Base Part Number	ZXTD720MC
