Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	LLE Series
Standard Package	2000
Manufacturer	Rubycon
Series	LLE
Packaging	Bulk
Part Status	Active
Capacitance	8.2µF
Tolerance	±20%
Voltage - Rated	200V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	12000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	66mA @ 120Hz
Ripple Current @ High Frequency	125mA @ 100kHz
Lead Spacing	0.138" (3.50mm)
Size / Dimension	0.315" Dia (8.00mm)
Height - Seated (Max)	0.433" (11.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

250LLE8.2MEFC10X9	Rubycon, 8.2µF 250V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C, LLE	View
400LLE6R8MEFC10X16	Rubycon, 6.8µF 400V Aluminum Electrolytic Capacitors Radial, Can 20000 Hrs @ 105°C, LLE	View
400LLE3.9MEFC10X12.5	Rubycon, 3.9µF 400V Aluminum Electrolytic Capacitors Radial, Can 15000 Hrs @ 105°C, LLE	View
450LLE33MEFC16X25	Rubycon, 33µF 450V Aluminum Electrolytic Capacitors Radial, Can 20000 Hrs @ 105°C, LLE	View
200LLE18MEFC10X12.5	Rubycon, 18µF 200V Aluminum Electrolytic Capacitors Radial, Can 15000 Hrs @ 105°C, LLE	View
450LLE22MEFC16X20	Rubycon, 22µF 450V Aluminum Electrolytic Capacitors Radial, Can 20000 Hrs @ 105°C, LLE	View
200LLE2R2MEFC6.3X11	Rubycon, 2.2µF 200V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C, LLE	View
400LLE1R5MEFC8X9	Rubycon, 1.5µF 400V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C, LLE	View
450LLE33MEFC18X20	Rubycon, 33µF 450V Aluminum Electrolytic Capacitors Radial, Can 20000 Hrs @ 105°C, LLE	View
400LLE4R7MEFC10X12.5	Rubycon, 4.7µF 400V Aluminum Electrolytic Capacitors Radial, Can 15000 Hrs @ 105°C, LLE	View
450LLE8.2MEFC10X20	Rubycon, 8.2µF 450V Aluminum Electrolytic Capacitors Radial, Can 20000 Hrs @ 105°C, LLE	View
450LLE47MEFC18X25	Rubycon, 47µF 450V Aluminum Electrolytic Capacitors Radial, Can 20000 Hrs @ 105°C, LLE	View

200LLE8R2MEFC8X9

Part Number200LLE8R2MEFC8X9
