2N2369A

2N2369A

Part Number2N2369A

ManufacturerMicrosemi Corporation

DescriptionTRANS NPN 15V TO18

Datasheet2N2369A, 2N4449

Package / CaseTO-206AA, TO-18-3 Metal Can

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor NPN 15V 360mW Through Hole TO-18 (TO-206AA)

To learn about the specification of 2N2369A, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add 2N2369A with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of 2N2369A.
We are offering 2N2369A for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

2N2369A - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Datasheet	2N2369A, 2N4449
Standard Package	1
Manufacturer	Microsemi Corporation
Series	-
Packaging	Bulk
Part Status	Active
Transistor Type	NPN
Voltage - Collector Emitter Breakdown (Max)	15V
Vce Saturation (Max) @ Ib, Ic	450mV @ 10mA, 100mA
Current - Collector Cutoff (Max)	400nA
DC Current Gain (hFE) (Min) @ Ic, Vce	20 @ 100mA, 1V
Power - Max	360mW
Frequency - Transition	-
Operating Temperature	-65°C ~ 200°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-206AA, TO-18-3 Metal Can
Supplier Device Package	TO-18 (TO-206AA)
