2SCR542F3TR

2SCR542F3TR

Part Number2SCR542F3TR

ManufacturerRohm Semiconductor

DescriptionNPN 3.0A 30V MIDDLE POWER TRANSI

Datasheet2SCR542F3 Datasheet

Package / Case3-UDFN Exposed Pad

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor NPN 30V 3A 250MHz 1W Surface Mount HUML2020L3

To learn about the specification of 2SCR542F3TR, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add 2SCR542F3TR with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of 2SCR542F3TR.
We are offering 2SCR542F3TR for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

2SCR542F3TR - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Datasheet	2SCR542F3 Datasheet
Standard Package	3000
Manufacturer	Rohm Semiconductor
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Transistor Type	NPN
Current - Collector (Ic) (Max)	3A
Voltage - Collector Emitter Breakdown (Max)	30V
Vce Saturation (Max) @ Ib, Ic	200mV @ 50mA, 1A
Current - Collector Cutoff (Max)	100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	200 @ 500mA, 2V
Power - Max	1W
Frequency - Transition	250MHz
Operating Temperature	150°C (TJ)
Mounting Type	Surface Mount
Package / Case	3-UDFN Exposed Pad
Supplier Device Package	HUML2020L3
