Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	AX Series
Standard Package	2000
Manufacturer	Rubycon
Series	AX
Packaging	Bulk
Part Status	Active
Capacitance	4.7µF
Tolerance	±20%
Voltage - Rated	400V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Lead Spacing	0.138" (3.50mm)
Size / Dimension	0.315" Dia (8.00mm)
Height - Seated (Max)	0.394" (10.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

6.3AX680MEFC8X9	Rubycon, 680µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, AX	View
8AX200MEFC5X11	Rubycon, 200µF 8V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, AX	View
10AX68MEFC5X7	Rubycon, 68µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, AX	View
400AX15MEFC10X16	Rubycon, 15µF 400V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, AX	View
AX-12.288MAGV-T	TXC CORPORATION, 12.288MHz ±30ppm Crystal 8pF 80 Ohms 2-SMD, No Lead, AX	View
6.3AX470MEFC6.3X11	Rubycon, 470µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, AX	View
400AX4R7MEFC6.3X14	Rubycon, 4.7µF 400V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, AX	View
400AX8R2MEFC8X16	Rubycon, 8.2µF 400V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, AX	View
10AX820MEFC10X9	Rubycon, 820µF 10V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, AX	View
8AX910MEFC8X16	Rubycon, 910µF 8V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, AX	View
10AX180MEFC5X11	Rubycon, 180µF 10V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, AX	View
10AX1000MEFC10X12.5	Rubycon, 1000µF 10V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, AX	View

400AX4.7MEFC8X9

Part Number400AX4.7MEFC8X9
