Categories	Capacitors / Film Capacitors
Datasheet	B32651-B32658 Series
Standard Package	510
Manufacturer	EPCOS (TDK)
Series	B32653
Packaging	Bulk
Part Status	Active
Capacitance	6800pF
Tolerance	±5%
Voltage Rating - AC	700V
Voltage Rating - DC	2000V (2kV)
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-55°C ~ 100°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	1.043" L x 0.335" W (26.50mm x 8.50mm)
Height - Seated (Max)	0.650" (16.50mm)
Termination	PC Pins
Lead Spacing	0.886" (22.50mm)
Applications	DC Link, DC Filtering; High Pulse, DV/DT
Ratings	-
Features	-
