Categories	Capacitors / Film Capacitors
Datasheet	B32774,76,78 Series
Standard Package	195
Manufacturer	EPCOS (TDK)
Series	B32776
Packaging	Bulk
Part Status	Active
Capacitance	16µF
Tolerance	±10%
Voltage Rating - AC	-
Voltage Rating - DC	450V
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-40°C ~ 105°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	1.634" L x 0.945" W (41.50mm x 24.00mm)
Height - Seated (Max)	0.748" (19.00mm)
Termination	PC Pins
Lead Spacing	1.476" (37.50mm)
Applications	DC Link, DC Filtering
Ratings	-
Features	Long Life

B32776G4406K000	EPCOS (TDK), 40µF Film Capacitor 450V Polypropylene (PP), Metallized Radial, B32776	View
B32776G8206K000	EPCOS (TDK), 20µF Film Capacitor 800V Polypropylene (PP), Metallized Radial, B32776	View
B32776T1275K000	EPCOS (TDK), 2.7µF Film Capacitor 1300V (1.3kV) Polypropylene (PP), Metallized Radial, B32776	View
B32778J0207K000	EPCOS (TDK), 200µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized 12-DIP, B32778	View
B32774D0205K000	EPCOS (TDK), 2µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial, B32774	View
B32776G0206K000	EPCOS (TDK), 20µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial, B32776	View
B32778G0306J000	EPCOS (TDK), 30µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial, B32778	View
B32778G8506K000	EPCOS (TDK), 50µF Film Capacitor 800V Polypropylene (PP), Metallized Radial, B32778	View
B32776T8855K000	EPCOS (TDK), 8.5µF Film Capacitor 800V Polypropylene (PP), Metallized Radial, B32776	View
B32776T0505K000	EPCOS (TDK), 5µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial, B32776	View
B32778J5367K000	EPCOS (TDK), 360µF Film Capacitor 575V Polypropylene (PP), Metallized 12-DIP, B32778	View
B32774D1505K000	EPCOS (TDK), 5µF Film Capacitor 1300V (1.3kV) Polypropylene (PP), Metallized Radial, B32774	View

B32776T4166K000

Part NumberB32776T4166K000
