Categories	Capacitors / Film Capacitors
Datasheet	B32774,76,78 Series
Standard Package	27
Manufacturer	EPCOS (TDK)
Series	B32778
Packaging	Bulk
Part Status	Active
Capacitance	40µF
Tolerance	±10%
Voltage Rating - AC	-
Voltage Rating - DC	1100V (1.1kV)
Dielectric Material	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance)	3.5 mOhms
Operating Temperature	-40°C ~ 105°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	2.264" L x 1.378" W (57.50mm x 35.00mm)
Height - Seated (Max)	1.969" (50.00mm)
Termination	PC Pins
Lead Spacing	2.067" (52.50mm)
Applications	DC Link, DC Filtering
Ratings	-
Features	Long Life

B32774D1505K000	EPCOS (TDK), 5µF Film Capacitor 1300V (1.3kV) Polypropylene (PP), Metallized Radial, B32774	View
B32774D4226K000	EPCOS (TDK), 22µF Film Capacitor 450V Polypropylene (PP), Metallized Radial, B32774	View
B32776G1106K000	EPCOS (TDK), 10µF Film Capacitor 1300V (1.3kV) Polypropylene (PP), Metallized Radial, B32776	View
B32776T8855K000	EPCOS (TDK), 8.5µF Film Capacitor 800V Polypropylene (PP), Metallized Radial, B32776	View
B32776G0146K000	EPCOS (TDK), 14µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial, B32776	View
B32778G1276K000	EPCOS (TDK), 27µF Film Capacitor 1300V (1.3kV) Polypropylene (PP), Metallized Radial, B32778	View
B32778J5367K000	EPCOS (TDK), 360µF Film Capacitor 575V Polypropylene (PP), Metallized 12-DIP, B32778	View
B32778G9506K000	EPCOS (TDK), 50µF Film Capacitor 900V Polypropylene (PP), Metallized Radial - 4 Leads, B32778	View
B32778J1127K000	EPCOS (TDK), 120µF Film Capacitor 1300V (1.3kV) Polypropylene (PP), Metallized 12-DIP, B32778	View
B32776T8685K000	EPCOS (TDK), 6.8µF Film Capacitor 875V Polypropylene (PP), Metallized Radial, B32776	View
B32776T4126K000	EPCOS (TDK), 12µF Film Capacitor 450V Polypropylene (PP), Metallized Radial, B32776	View
B32778G0306K000	EPCOS (TDK), 30µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial, B32778	View

B32778G0406K000

Part NumberB32778G0406K000
