Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	B78108E, B78148E Series
Standard Package	1
Manufacturer	EPCOS (TDK)
Series	B78108E
Packaging	Cut Tape (CT)
Part Status	Active
Type	Wirewound
Material - Core	Ferrite
Inductance	15µH
Tolerance	±10%
Current Rating (Amps)	1.6A
Current - Saturation	1.45A
Shielding	Unshielded
DC Resistance (DCR)	230mOhm Max
Q @ Freq	40 @ 796kHz
Frequency - Self Resonant	15MHz
Ratings	-
Operating Temperature	-55°C ~ 125°C
Inductance Frequency - Test	100kHz
Features	-
Mounting Type	Through Hole
Package / Case	Axial
Supplier Device Package	Axial
Size / Dimension	0.157" Dia x 0.374" L (4.00mm x 9.50mm)
Height - Seated (Max)	-

B78108E1104J009	EPCOS (TDK), 100µH Unshielded Wirewound Inductor 640mA 1.45Ohm Max Axial, B78108E	View
B78108S1394J000	EPCOS (TDK), 390µH Unshielded Wirewound Inductor 180mA 7Ohm Max Axial, BC	View
B78148E1472K000	EPCOS (TDK), 4.7µH Unshielded Wirewound Inductor 2.75A 85mOhm Max Radial, BC+	View
B78108S1105J000	EPCOS (TDK), 1mH Unshielded Wirewound Inductor 130mA 14Ohm Max Axial, BC	View
B78108E1153K009	EPCOS (TDK), 15µH Unshielded Wirewound Inductor 1.6A 230mOhm Max Axial, B78108E	View
B78108S1185J000	EPCOS (TDK), 1.8mH Unshielded Wirewound Inductor 95mA 26Ohm Max Axial, BC	View
B78108E1101M000	EPCOS (TDK), 100nH Unshielded Wirewound Inductor 7.3A 15mOhm Max Axial, BC+	View
B78148E1152K000	EPCOS (TDK), 1.5µH Unshielded Wirewound Inductor 3.8A 47mOhm Max Radial, BC+	View
B78108S1562K000	EPCOS (TDK), 5.6µH Unshielded Wirewound Inductor 780mA 380mOhm Max Axial, BC	View
B78108S1335J000	EPCOS (TDK), 3.3mH Unshielded Wirewound Inductor 62mA 59.5Ohm Max Axial, BC	View
B78108E1471M009	EPCOS (TDK), 470nH Unshielded Wirewound Inductor 5A 27mOhm Max Axial, B78108E	View
B78108E1331M000	EPCOS (TDK), 330nH Unshielded Wirewound Inductor 5.3A 23mOhm Max Axial, BC+	View

B78108E1153K009

Part NumberB78108E1153K009
