Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	B82144B2 Series
Standard Package	1
Manufacturer	EPCOS (TDK)
Series	LBC
Packaging	Cut Tape (CT)
Part Status	Active
Type	Wirewound
Material - Core	Ferrite
Inductance	180µH
Tolerance	±5%
Current Rating (Amps)	950mA
Current - Saturation	720mA
Shielding	Unshielded
DC Resistance (DCR)	785mOhm Max
Q @ Freq	40 @ 79.6kHz
Frequency - Self Resonant	4MHz
Ratings	-
Operating Temperature	-55°C ~ 125°C
Inductance Frequency - Test	100kHz
Mounting Type	Through Hole
Package / Case	Radial, Vertical Cylinder
Supplier Device Package	-
Size / Dimension	0.256" Dia (6.50mm)
Height - Seated (Max)	0.551" (14.00mm)

B82144B2182K000	EPCOS (TDK), 1.8µH Unshielded Wirewound Inductor 3.75A 50mOhm Max Radial, Vertical Cylinder, LBC	View
B82144B2683J000	EPCOS (TDK), 68µH Unshielded Wirewound Inductor 1.5A 350mOhm Max Radial, Vertical Cylinder, LBC	View
B82144A2106J000	EPCOS (TDK), 10mH Unshielded Wirewound Inductor 60mA 42Ohm Max Axial, LBC	View
B82144F2822K000	EPCOS (TDK), 8.2µH Unshielded Wirewound Inductor 2.65A 105mOhm Max Axial, LBC	View
B82144B2123K000	EPCOS (TDK), 12µH Unshielded Wirewound Inductor 2.4A 130mOhm Max Radial, Vertical Cylinder, LBC	View
B82144A2474J000	EPCOS (TDK), 470µH Unshielded Wirewound Inductor 280mA 2.5Ohm Max Axial, LBC	View
B82144B2563J000	EPCOS (TDK), 56µH Unshielded Wirewound Inductor 1.6A 310mOhm Max Radial, Vertical Cylinder, LBC	View
B82144B2393J000	EPCOS (TDK), 39µH Unshielded Wirewound Inductor 1.75A 250mOhm Max Radial, Vertical Cylinder, LBC	View
B82144F2152K000	EPCOS (TDK), 1.5µH Unshielded Wirewound Inductor 4.1A 45mOhm Max Axial, LBC	View
B82144A2155J000	EPCOS (TDK), 1.5mH Unshielded Wirewound Inductor 160mA 6Ohm Max Axial, LBC	View
B82144B1105J000	EPCOS (TDK), 1mH Unshielded Wirewound Inductor 280mA 4.2Ohm Max Radial, Vertical Cylinder, LBC	View
B82144B2333J000	EPCOS (TDK), 33µH Unshielded Wirewound Inductor 1.9A 220mOhm Max Radial, Vertical Cylinder, LBC	View

B82144B2184J000

Part NumberB82144B2184J000
