Part Number B82723A2602N001 Description COMMON MODE CHOKE 1MH 6A 2LN TH Package / Case Horizontal, 4 PC PinUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description 1mH @ 100kHz 2 Line Common Mode Choke Through Hole 6A DCR 22mOhm (Typ)
To learn about the specification of B82723A2602N001, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add B82723A2602N001 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of B82723A2602N001.
We are offering B82723A2602N001 for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
B82723A2602N001 - Product Attributes
Categories
Filters / Common Mode Chokes
Datasheet B82723A,J Series Datasheet Standard Package 400 Manufacturer EPCOS (TDK) Series B82723 Packaging Tray Part Status Active Filter Type Power Line Number of Lines 2 Inductance @ Frequency 1mH @ 100kHz Current Rating (Max) 6A DC Resistance (DCR) (Max) 22mOhm (Typ) Voltage Rating - DC - Voltage Rating - AC 250V Operating Temperature -40°C ~ 125°C Ratings - Approvals ENEC, UR, VDE Features - Mounting Type Through Hole Size / Dimension 1.102" L x 1.063" W (28.00mm x 27.00mm) Height (Max) 0.661" (16.80mm) Package / Case Horizontal, 4 PC Pin
