B82791H2301N001
B82791H2301N001
Part Number B82791H2301N001 Description CMC 30MH 300MA 2LN TH Package / Case Vertical, 4 PC PinUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description 30mH @ 10kHz 2 Line Common Mode Choke Through Hole 300mA DCR 2.2Ohm (Typ)
To learn about the specification of B82791H2301N001, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add B82791H2301N001 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of B82791H2301N001.
We are offering B82791H2301N001 for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
B82791H2301N001 - Product Attributes
Categories
Filters / Common Mode Chokes
Datasheet B82791G2,H2 Standard Package 200 Manufacturer EPCOS (TDK) Series B82791 Packaging Bulk Part Status Active Filter Type Power Line Number of Lines 2 Inductance @ Frequency 30mH @ 10kHz Current Rating (Max) 300mA DC Resistance (DCR) (Max) 2.2Ohm (Typ) Voltage Rating - DC - Voltage Rating - AC 250V Operating Temperature -40°C ~ 125°C Ratings - Approvals ENEC, UR, VDE Features - Mounting Type Through Hole Size / Dimension 0.602" L x 0.291" W (15.30mm x 7.40mm) Height (Max) 0.693" (17.60mm) Package / Case Vertical, 4 PC Pin
B82791H2301N001 - Related ProductsMore >>
B82791G2251N020 EPCOS (TDK), 47mH @ 10kHz 2 Line Common Mode Choke Through Hole 250mA DCR 2.4Ohm (Typ), B82791
View
B82791H2351N001 EPCOS (TDK), 22mH @ 10kHz 2 Line Common Mode Choke Through Hole 350mA DCR 1.9Ohm (Typ), B82791
View
B82791H2701N001 EPCOS (TDK), 4.7mH @ 10kHz 2 Line Common Mode Choke Through Hole 700mA DCR 440mOhm (Typ), B82791
View
B82791H2501N001 EPCOS (TDK), 10mH @ 10kHz 2 Line Common Mode Choke Through Hole 500mA DCR 1Ohm (Typ), B82791
View
B82791G0015A016 EPCOS (TDK), 4.7mH @ 10kHz 2 Line Common Mode Choke Through Hole 100mA DCR 850mOhm (Typ), B82791
View
B82791H2401N001 EPCOS (TDK), 2 Line Common Mode Choke Through Hole 400mA DCR 1.35Ohm (Typ), B82791
View
B82791H0015A016 EPCOS (TDK), 4.7mH @ 10kHz 2 Line Common Mode Choke Through Hole 100mA DCR 850mOhm (Typ), B82791
View
B82791H0015A025 EPCOS (TDK), 10mH @ 10kHz 2 Line Common Mode Choke Through Hole 100mA DCR 1.2Ohm (Typ), B82791
View
B82791G0014A016 EPCOS (TDK), 4.7mH @ 10kHz 4 Line Common Mode Choke Through Hole 100mA DCR 850mOhm (Typ), B82791
View
B82791H2601N001 EPCOS (TDK), 6.8mH @ 10kHz 2 Line Common Mode Choke Through Hole 600mA DCR 630mOhm (Typ), B82791
View
B82791G2301N001 EPCOS (TDK), 30mH @ 10kHz 2 Line Common Mode Choke Through Hole 300mA DCR 2.2Ohm (Typ), B82791
View
B82791H2301N001 EPCOS (TDK), 30mH @ 10kHz 2 Line Common Mode Choke Through Hole 300mA DCR 2.2Ohm (Typ), B82791
View
