BRL3225T2R2M

BRL3225T2R2M

Part NumberBRL3225T2R2M

ManufacturerTaiyo Yuden

DescriptionFIXED IND 2.2UH 1.6A 78 MOHM SMD

DatasheetBRL3225T2R2M View all Specification

Package / Case1210 (3225 Metric)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description2.2µH Unshielded Wirewound Inductor 1.6A 78mOhm Max 1210 (3225 Metric)

To learn about the specification of BRL3225T2R2M, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add BRL3225T2R2M with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of BRL3225T2R2M.
We are offering BRL3225T2R2M for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

BRL3225T2R2M - Product Attributes

Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	BRL3225T2R2M View all Specification
Standard Package	1
Manufacturer	Taiyo Yuden
Series	BR, L Type
Packaging	Cut Tape (CT)
Part Status	Active
Type	Wirewound
Material - Core	Ferrite
Inductance	2.2µH
Tolerance	±20%
Current Rating (Amps)	1.6A
Current - Saturation	1.85A
Shielding	Unshielded
DC Resistance (DCR)	78mOhm Max
Q @ Freq	-
Frequency - Self Resonant	150MHz
Ratings	-
Operating Temperature	-40°C ~ 105°C
Inductance Frequency - Test	100kHz
Mounting Type	Surface Mount
Package / Case	1210 (3225 Metric)
Supplier Device Package	1210
Size / Dimension	0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max)	0.067" (1.70mm)
