Categories	Capacitors / Film Capacitors
Datasheet	C4AE Series
Standard Package	234
Manufacturer	KEMET
Series	C4AE
Packaging	Bulk
Part Status	Active
Capacitance	6.8µF
Tolerance	±5%
Voltage Rating - AC	-
Voltage Rating - DC	450V
Dielectric Material	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance)	10 mOhms
Operating Temperature	-40°C ~ 85°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	1.240" L x 0.512" W (31.50mm x 13.00mm)
Height - Seated (Max)	0.992" (25.20mm)
Termination	PC Pins
Lead Spacing	1.083" (27.50mm)
Applications	DC Link, DC Filtering; High Frequency, Switching
Ratings	-
Features	-
