Categories	Capacitors / Film Capacitors
Datasheet	C4AQ Series, Automotive Datasheet
Standard Package	27
Manufacturer	KEMET
Series	C4AQ
Packaging	Bulk
Part Status	Active
Capacitance	100µF
Tolerance	±10%
Voltage Rating - AC	-
Voltage Rating - DC	500V
Dielectric Material	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance)	3 mOhms
Operating Temperature	-40°C ~ 105°C
Mounting Type	Through Hole
Package / Case	Radial - 4 Leads
Size / Dimension	2.264" L x 1.181" W (57.50mm x 30.00mm)
Height - Seated (Max)	1.783" (45.30mm)
Termination	PC Pins
Lead Spacing	2.067" (52.50mm)
Applications	Automotive; DC Link, DC Filtering
Ratings	AEC-Q200
Features	-

C4AQIBW5600A3NJ	KEMET, 60µF Film Capacitor 800V Polypropylene (PP), Metallized Radial - 4 Leads, C4AQ	View
C4AQUBW5250A3NJ	KEMET, 25µF Film Capacitor 1300V (1.3kV) Polypropylene (PP), Metallized Radial - 4 Leads, C4AQ	View
C4AQIBW5200A3JJ	KEMET, 20µF Film Capacitor 800V Polypropylene (PP), Metallized Radial - 4 Leads, C4AQ	View
C4AQCBW5400A3LJ	KEMET, 40µF Film Capacitor 650V Polypropylene (PP), Metallized Radial - 4 Leads, C4AQ	View
C4AQQBW5400A3NJ	KEMET, 40µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial - 4 Leads, C4AQ	View
C4AQUBU4220A1YJ	KEMET, 2.2µF Film Capacitor 1300V (1.3kV) Polypropylene (PP), Metallized Radial, C4AQ	View
C4AQIBW5550A3NJ	KEMET, 55µF Film Capacitor 800V Polypropylene (PP), Metallized Radial - 4 Leads, C4AQ	View
C4AQLBU5250A12K	KEMET, 25µF Film Capacitor 500V Polypropylene (PP), Metallized Radial, C4AQ	View
C4AQUBU4180A1XJ	KEMET, 1.8µF Film Capacitor 1300V (1.3kV) Polypropylene (PP), Metallized Radial, C4AQ	View
C4AQSBU4300A11J	KEMET, 3µF Film Capacitor 1500V (1.5kV) Polypropylene (PP), Metallized Radial, C4AQ	View
C4AQSBW5170A3MJ	KEMET, 17µF Film Capacitor 1500V (1.5kV) Polypropylene (PP), Metallized Radial - 4 Leads, C4AQ	View
C4AQQBW5250A3OJ	KEMET, 25µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial - 4 Leads, C4AQ	View

C4AQLBW6100A3MK

Part NumberC4AQLBW6100A3MK
