Categories	Capacitors / Film Capacitors
Datasheet	CB Series Datasheet
Standard Package	1
Manufacturer	AVX Corporation
Series	CB
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	1µF
Tolerance	±5%
Voltage Rating - AC	63V
Voltage Rating - DC	100V
Dielectric Material	Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked
Operating Temperature	-55°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	2824 (7260 Metric)
Size / Dimension	0.283" L x 0.240" W (7.20mm x 6.10mm)
Height - Seated (Max)	0.224" (5.70mm)
Termination	Solder Pads
Lead Spacing	-
Applications	General Purpose
Ratings	-
Features	-
