Categories	Capacitors / Film Capacitors
Datasheet	ECQ-UL Series Datasheet
Standard Package	100
Manufacturer	Panasonic Electronic Components
Series	ECQ-UL
Packaging	Bulk
Part Status	Active
Capacitance	0.33µF
Tolerance	±20%
Voltage Rating - AC	275V
Voltage Rating - DC	-
Dielectric Material	Polyester, Metallized
Operating Temperature	-40°C ~ 100°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	0.689" L x 0.374" W (17.50mm x 9.50mm)
Height - Seated (Max)	0.709" (18.00mm)
Termination	PC Pins
Lead Spacing	0.591" (15.00mm)
Applications	EMI, RFI Suppression
Ratings	X2
Features	-

ECQ-U2A823ML	Panasonic Electronic Components, 0.082µF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View
ECQ-U2A822ML	Panasonic Electronic Components, 8200pF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View
ECQ-U2A562ML	Panasonic Electronic Components, 5600pF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View
ECQ-U2A224ML	Panasonic Electronic Components, 0.22µF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View
ECQ-U2A102ML	Panasonic Electronic Components, 1000pF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View
ECQ-U2A273ML	Panasonic Electronic Components, 0.027µF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View
ECQ-U2A683ML	Panasonic Electronic Components, 0.068µF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View
ECQ-U2A393ML	Panasonic Electronic Components, 0.039µF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View
ECQ-U2A182ML	Panasonic Electronic Components, 1800pF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View
ECQ-U2A154ML	Panasonic Electronic Components, 0.15µF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View
ECQ-U2A104ML	Panasonic Electronic Components, 0.1µF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View
ECQ-U2A682ML	Panasonic Electronic Components, 6800pF Film Capacitor 275V Polyester, Metallized Radial, ECQ-UL	View

ECQ-U2A334ML

Part NumberECQ-U2A334ML
