FP0505R1-R100-R

Part NumberFP0505R1-R100-R

ManufacturerEaton - Electronics Division

DescriptionFIXED IND 100NH 30A 0.38 MOHM

DatasheetFP0505R1 Series Datasheet

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description100nH Unshielded Inductor 30A 0.38mOhm Nonstandard

To learn about the specification of FP0505R1-R100-R, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add FP0505R1-R100-R with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of FP0505R1-R100-R.
We are offering FP0505R1-R100-R for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

FP0505R1-R100-R - Product Attributes

Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	FP0505R1 Series Datasheet
Standard Package	1
Manufacturer	Eaton - Electronics Division
Series	FP0505R
Packaging	Cut Tape (CT)
Part Status	Active
Type	-
Material - Core	Ferrite
Inductance	100nH
Tolerance	±10%
Current Rating (Amps)	30A
Current - Saturation	24A
Shielding	Unshielded
DC Resistance (DCR)	0.38mOhm
Q @ Freq	-
Frequency - Self Resonant	-
Ratings	-
Operating Temperature	-40°C ~ 125°C
Inductance Frequency - Test	100kHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.197" L x 0.197" W (5.00mm x 5.00mm)
Height - Seated (Max)	0.189" (4.80mm)
