Categories	Capacitors / Trimmers, Variable Capacitors
Datasheet	GXEyy000NM Drawing*
Standard Package	100
Manufacturer	Sprague-Goodman
Series	GXE
Packaging	Bulk
Part Status	Active
Capacitance Range	3.5 ~ 27pF
Adjustment Type	Top and Bottom
Voltage - Rated	200V
Dielectric Material	Polytetrafluoroethylene (PTFE)
Q @ Freq	1500 @ 1MHz
Size / Dimension	0.335" L x 0.295" W (8.50mm x 7.50mm)
Height - Seated (Max)	0.402" (10.20mm)
Operating Temperature	-40°C ~ 125°C
Mounting Type	Through Hole
Features	Non-Magnetic
