Categories	Capacitors / Ceramic Capacitors
Datasheet	Hi-Q High RF Power
Standard Package	24
Manufacturer	AVX Corporation
Series	Hi-Q®
Packaging	Tray
Part Status	Active
Capacitance	100pF
Tolerance	±5%
Voltage - Rated	7200V (7.2kV)
Temperature Coefficient	C0G, NP0
Operating Temperature	-55°C ~ 125°C
Features	High Q, Low Loss, Ultra Low ESR, High Voltage
Ratings	-
Applications	RF, Microwave, High Frequency
Mounting Type	Surface Mount, MLCC
Package / Case	3838 (9797 Metric)
Size / Dimension	0.380" L x 0.380" W (9.65mm x 9.65mm)
Height - Seated (Max)	-
Thickness (Max)	0.170" (4.32mm)
Lead Spacing	-
Lead Style	-
