IPT012N08N5ATMA1

IPT012N08N5ATMA1

Part NumberIPT012N08N5ATMA1

ManufacturerInfineon Technologies

DescriptionMOSFET N-CH 80V 300A 8HSOF

DatasheetIPT012N08N5

Package / Case8-PowerSFN

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 80V 300A (Tc) 375W (Tc) Surface Mount PG-HSOF-8-1

To learn about the specification of IPT012N08N5ATMA1, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add IPT012N08N5ATMA1 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of IPT012N08N5ATMA1.
We are offering IPT012N08N5ATMA1 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

IPT012N08N5ATMA1 - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	IPT012N08N5
Standard Package	2000
Manufacturer	Infineon Technologies
Series	OptiMOS™
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	80V
Current - Continuous Drain (Id) @ 25°C	300A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	6V, 10V
Rds On (Max) @ Id, Vgs	1.2mOhm @ 150A, 10V
Vgs(th) (Max) @ Id	3.8V @ 280µA
Gate Charge (Qg) (Max) @ Vgs	223nC @ 10V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	17000pF @ 40V
FET Feature	-
Power Dissipation (Max)	375W (Tc)
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	PG-HSOF-8-1
Package / Case	8-PowerSFN
