IXGK75N250
IXGK75N250
Part Number IXGK75N250
Manufacturer IXYS
Description IGBT 2500V 170A 780W TO264
Package / Case TO-264-3, TO-264AA
Unit Price Request a Quote
Lead Time To be Confirmed
Detailed Description IGBT NPT 2500V 170A 780W Through Hole TO-264 (IXGK)
To learn about the specification of IXGK75N250, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add IXGK75N250 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of IXGK75N250.
We are offering IXGK75N250 for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
IXGK75N250 - Product Attributes
Categories
Discrete Semiconductor Products / Transistors - IGBTs - Single
Datasheet IXGx75N250
Standard Package 25
Manufacturer IXYS
Series -
Packaging Tube
Part Status Active
IGBT Type NPT
Voltage - Collector Emitter Breakdown (Max) 2500V
Current - Collector (Ic) (Max) 170A
Current - Collector Pulsed (Icm) 530A
Vce(on) (Max) @ Vge, Ic 3.6V @ 15V, 150A
Power - Max 780W
Switching Energy -
Input Type Standard
Gate Charge 410nC
Td (on/off) @ 25°C -
Test Condition -
Operating Temperature -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case TO-264-3, TO-264AA
Supplier Device Package TO-264 (IXGK)
