JANTX1N4956


JANTX1N4956

Part NumberJANTX1N4956

Manufacturer

Description

Datasheet

Package / CaseE, Axial

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

JANTX1N4956 - Product Attributes

Categories Discrete Semiconductor Products / Diodes - Zener - Single
Datasheet
Standard Package1
ManufacturerMicrosemi Corporation
SeriesMilitary, MIL-PRF-19500/356
PackagingBulk
Part StatusActive
Voltage - Zener (Nom) (Vz)8.2V
Tolerance±5%
Power - Max5W
Impedance (Max) (Zzt)1.5 Ohms
Current - Reverse Leakage @ Vr50µA @ 6.2V
Voltage - Forward (Vf) (Max) @ If1.5V @ 1A
Operating Temperature-65°C ~ 175°C
Mounting TypeThrough Hole
Package / CaseE, Axial
Supplier Device Package-
Base Part Number1N4956
