Categories	Capacitors / Electric Double Layer Capacitors (EDLC), Supercapacitors
Datasheet	UM Series EVerCAP Datasheet
Standard Package	200
Manufacturer	Nichicon
Series	EVerCAP® JUM
Packaging	Bulk
Part Status	Active
Capacitance	470mF
Tolerance	±20%
Voltage - Rated	2.7V
ESR (Equivalent Series Resistance)	4Ohm @ 1kHz
Lifetime @ Temp.	1000 Hrs @ 70°C
Termination	PC Pins
Mounting Type	Through Hole
Package / Case	Radial, Can
Lead Spacing	0.098" (2.50mm)
Size / Dimension	0.248" Dia (6.30mm)
Height - Seated (Max)	0.413" (10.50mm)
Operating Temperature	-25°C ~ 70°C

JUMT1105MPD	Nichicon, 1F (EDLC) Supercapacitor 2.7V Radial, Can 2Ohm @ 1kHz 1000 Hrs @ 70°C, EVerCAP® JUM	View
JUMT1335MPD	Nichicon, 3.3F (EDLC) Supercapacitor 2.7V Radial, Can 1Ohm @ 1kHz 1000 Hrs @ 70°C, EVerCAP® JUM	View
JUMT1106MHD	Nichicon, 10F (EDLC) Supercapacitor 2.7V Radial, Can 200mOhm @ 1kHz 1000 Hrs @ 70°C, EVerCAP® JUM	View
JUMT1226MHD	Nichicon, 22F (EDLC) Supercapacitor 2.7V Radial, Can 200mOhm @ 1kHz 1000 Hrs @ 70°C, EVerCAP® JUM	View
JUMT1474MED	Nichicon, 470mF (EDLC) Supercapacitor 2.7V Radial, Can 4Ohm @ 1kHz 1000 Hrs @ 70°C, EVerCAP® JUM	View
JUMT1476MHD	Nichicon, 47F (EDLC) Supercapacitor 2.7V Radial, Can 100mOhm @ 1kHz 1000 Hrs @ 70°C, EVerCAP® JUM	View
JUM0H184ACD	Nichicon, 180mF (EDLC) Supercapacitor 5.5V Radial, Can 2Ohm 1000 Hrs @ 70°C, EVerCAP® JUM	View
JUMT1336MHD	Nichicon, 33F (EDLC) Supercapacitor 2.7V Radial, Can 100mOhm @ 1kHz 1000 Hrs @ 70°C, EVerCAP® JUM	View
JUMT1225MPD	Nichicon, 2.2F (EDLC) Supercapacitor 2.7V Radial, Can 2Ohm @ 1kHz 1000 Hrs @ 70°C, EVerCAP® JUM	View
JUMT1475MHD	Nichicon, 4.7F (EDLC) Supercapacitor 2.7V Radial, Can 400mOhm @ 1kHz 1000 Hrs @ 70°C, EVerCAP® JUM	View

JUMT1474MED

Part NumberJUMT1474MED
