LQW18CA56NJ00D

Part NumberLQW18CA56NJ00D

ManufacturerMurata Electronics North America

DescriptionFIXED IND 56NH 1850MA 40MOHM

DatasheetLQW18CAyyyy00D

Package / Case0603 (1608 Metric)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description56nH Unshielded Wirewound Inductor 1.85A 40mOhm Max 0603 (1608 Metric)

To learn about the specification of LQW18CA56NJ00D, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add LQW18CA56NJ00D with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of LQW18CA56NJ00D.
We are offering LQW18CA56NJ00D for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

LQW18CA56NJ00D - Product Attributes

Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	LQW18CAyyyy00D
Standard Package	4000
Manufacturer	Murata Electronics North America
Series	LQW18
Packaging	Tape & Reel (TR)
Part Status	Active
Type	Wirewound
Material - Core	Ferrite
Inductance	56nH
Tolerance	±5%
Current Rating (Amps)	1.85A
Current - Saturation	-
Shielding	Unshielded
DC Resistance (DCR)	40mOhm Max
Q @ Freq	-
Frequency - Self Resonant	2.2GHz
Ratings	-
Operating Temperature	-40°C ~ 85°C
Inductance Frequency - Test	10MHz
Features	-
Mounting Type	Surface Mount
Package / Case	0603 (1608 Metric)
Supplier Device Package	0603
Size / Dimension	0.063" L x 0.031" W (1.60mm x 0.80mm)
Height - Seated (Max)	0.037" (0.95mm)
