MCU80N03-TP
MCU80N03-TP
Part Number MCU80N03-TP Description N-CHANNEL MOSFET, DPAK PACKAGE Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63Unit Price Request a QuoteLead Time To be ConfirmedDetailed Description N-Channel 30V 80A (Tc) 70W (Tc) Surface Mount D-Pak
To learn about the specification of MCU80N03-TP, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add MCU80N03-TP with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of MCU80N03-TP.
We are offering MCU80N03-TP for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
MCU80N03-TP - Product Attributes
Categories
Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Standard Package 2500 Manufacturer Micro Commercial Co Series - Packaging Tape & Reel (TR) Part Status Active FET Type N-Channel Technology MOSFET (Metal Oxide) Drain to Source Voltage (Vdss) 30V Current - Continuous Drain (Id) @ 25°C 80A (Tc) Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V Rds On (Max) @ Id, Vgs 4mOhm @ 18A, 10V Vgs(th) (Max) @ Id 2.5V @ 250µA Gate Charge (Qg) (Max) @ Vgs 28nC @ 10V Vgs (Max) ±20V Input Capacitance (Ciss) (Max) @ Vds 1600pF @ 15V FET Feature - Power Dissipation (Max) 70W (Tc) Operating Temperature -55°C ~ 175°C (TJ) Mounting Type Surface Mount Supplier Device Package D-Pak Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
