NJL3281DG

NJL3281DG

Part NumberNJL3281DG

ManufacturerON Semiconductor

DescriptionTRANS NPN 260V 15A TO-264

DatasheetNJL3281,1302D

Package / CaseTO-264-5

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor NPN 260V 15A 30MHz 200W Through Hole TO-264

To learn about the specification of NJL3281DG, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add NJL3281DG with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of NJL3281DG.
We are offering NJL3281DG for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

NJL3281DG - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Datasheet	NJL3281,1302D
Standard Package	25
Manufacturer	ON Semiconductor
Series	-
Packaging	Tube
Part Status	Active
Transistor Type	NPN
Current - Collector (Ic) (Max)	15A
Voltage - Collector Emitter Breakdown (Max)	260V
Vce Saturation (Max) @ Ib, Ic	3V @ 1A, 10A
Current - Collector Cutoff (Max)	50µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	75 @ 5A, 5V
Power - Max	200W
Frequency - Transition	30MHz
Operating Temperature	-65°C ~ 150°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-264-5
Supplier Device Package	TO-264
