P0146NL


P0146NL

Part NumberP0146NL

Manufacturer

Description

Datasheet

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

P0146NL - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package40
ManufacturerPulse Electronics Power
SeriesBobcat
PackagingTube
Part StatusActive
TypeToroidal
Material - Core-
Inductance25µH
Tolerance-
Current Rating (Amps)2.43A
Current - Saturation-
ShieldingUnshielded
DC Resistance (DCR)75mOhm Max
Q @ Freq-
Frequency - Self Resonant-
Ratings-
Operating Temperature-40°C ~ 130°C
Features-
Mounting TypeSurface Mount
Package / CaseNonstandard
Supplier Device Package-
Size / Dimension0.500" L x 0.500" W (12.70mm x 12.70mm)
Height - Seated (Max)0.215" (5.46mm)
