Part Number P0179NL Description INDUCT ARRAY 2 COIL 22.1UH SMD Package / Case NonstandardUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description Unshielded 2 Coil Inductor Array 88.2µH Inductance - Connected in Series 22.1µH Inductance - Connected in Parallel 66.3mOhm Max DC Resistance (DCR) - Parallel 2.6A Nonstandard
To learn about the specification of P0179NL, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add P0179NL with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of P0179NL.
We are offering P0179NL for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
P0179NL - Product Attributes
Categories
Inductors, Coils, Chokes / Arrays, Signal Transformers
Datasheet P01xxNL Polecat Series Standard Package 40 Manufacturer Pulse Electronics Power Series Polecat Packaging Tube Part Status Active Number of Coils 2 Inductance - Connected In Parallel 22.1µH Inductance - Connected In Series 88.2µH Tolerance ±10% Current Rating - Parallel 2.6A Current Rating - Series 1.3A DC Resistance (DCR) - Parallel 66.3mOhm Max DC Resistance (DCR) - Series 266mOhm Max Shielding Unshielded Ratings - Operating Temperature -40°C ~ 130°C Mounting Type Surface Mount Package / Case Nonstandard Size / Dimension 0.500" L x 0.500" W (12.70mm x 12.70mm) Height 0.215" (5.46mm)
P0177NLT Pulse Electronics Power, Unshielded 2 Coil Inductor Array 41.7µH Inductance - Connected in Series 10.4µH Inductance - Connected in Parallel 29.8mOhm Max DC Resistance (DCR) - Parallel 3.8A Nonstandard, Polecat
View
P0179NL Pulse Electronics Power, Unshielded 2 Coil Inductor Array 88.2µH Inductance - Connected in Series 22.1µH Inductance - Connected in Parallel 66.3mOhm Max DC Resistance (DCR) - Parallel 2.6A Nonstandard, Polecat
View
P0183NL Pulse Electronics Power, Unshielded 2 Coil Inductor Array 364µH Inductance - Connected in Series 91µH Inductance - Connected in Parallel 324mOhm Max DC Resistance (DCR) - Parallel 1.2A Nonstandard, Polecat
View
P0180NL Pulse Electronics Power, Unshielded 2 Coil Inductor Array 131µH Inductance - Connected in Series 32.8µH Inductance - Connected in Parallel 106mOhm Max DC Resistance (DCR) - Parallel 2.2A Nonstandard, Polecat
View
P0174NL Pulse Electronics Power, Unshielded 2 Coil Inductor Array 8.75µH Inductance - Connected in Series 2.2µH Inductance - Connected in Parallel 7.6mOhm Max DC Resistance (DCR) - Parallel 8.3A Nonstandard, Polecat
View
P0181NL Pulse Electronics Power, Unshielded 2 Coil Inductor Array 190.3µH Inductance - Connected in Series 47.6µH Inductance - Connected in Parallel 151mOhm Max DC Resistance (DCR) - Parallel 1.8A Nonstandard, Polecat
View
P0177NL Pulse Electronics Power, Unshielded 2 Coil Inductor Array 41.7µH Inductance - Connected in Series 10.4µH Inductance - Connected in Parallel 29.8mOhm Max DC Resistance (DCR) - Parallel 3.8A Nonstandard, Polecat
View
P0175NL Pulse Electronics Power, Unshielded 2 Coil Inductor Array 10.4µH Inductance - Connected in Series 2.6µH Inductance - Connected in Parallel 10.9mOhm Max DC Resistance (DCR) - Parallel 7.2A Nonstandard, Polecat
View
P0177NLT Pulse Electronics Power, Unshielded 2 Coil Inductor Array 41.7µH Inductance - Connected in Series 10.4µH Inductance - Connected in Parallel 29.8mOhm Max DC Resistance (DCR) - Parallel 3.8A Nonstandard, Polecat
View
