Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	PLG Series Datasheet
Standard Package	200
Manufacturer	Nichicon
Series	PLG
Packaging	Bulk
Part Status	Active
Type	Polymer
Capacitance	820µF
Tolerance	±20%
Voltage - Rated	16V
ESR (Equivalent Series Resistance)	11mOhm
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Ratings	-
Applications	General Purpose
Ripple Current @ High Frequency	5.6A @ 100kHz
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.394" Dia (10.00mm)
Height - Seated (Max)	0.512" (13.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

PLG0J122MDO1TD	Nichicon, 1200µF 6.3V Aluminum Polymer Capacitor Radial, Can 9mOhm 2000 Hrs @ 105°C, PLG	View
PLG0E182MCO1TD	Nichicon, 1800µF 2.5V Aluminum Polymer Capacitor Radial, Can 9mOhm 2000 Hrs @ 105°C, PLG	View
PLG1A561MCO1TD	Nichicon, 560µF 10V Aluminum Polymer Capacitor Radial, Can 11mOhm 2000 Hrs @ 105°C, PLG	View
PLG1C331MCO1TD	Nichicon, 330µF 16V Aluminum Polymer Capacitor Radial, Can 13mOhm 2000 Hrs @ 105°C, PLG	View
PLG0E272MDO1TD	Nichicon, 2700µF 2.5V Aluminum Polymer Capacitor Radial, Can 8mOhm 2000 Hrs @ 105°C, PLG	View
PLG0E222MDO1TD	Nichicon, 2200µF 2.5V Aluminum Polymer Capacitor Radial, Can 8mOhm 2000 Hrs @ 105°C, PLG	View
PLG0G182MDO1TD	Nichicon, 1800µF 4V Aluminum Polymer Capacitor Radial, Can 9mOhm 2000 Hrs @ 105°C, PLG	View
PLG0G122MCO1TD	Nichicon, 1200µF 4V Aluminum Polymer Capacitor Radial, Can 9mOhm 2000 Hrs @ 105°C, PLG	View
PLG1A122MDO1	Nichicon, 1200µF 10V Aluminum Polymer Capacitor Radial, Can 9mOhm 2000 Hrs @ 105°C, PLG	View
PLG1C471MDO1TD	Nichicon, 470µF 16V Aluminum Polymer Capacitor Radial, Can 11mOhm 2000 Hrs @ 105°C, PLG	View
PLG0J152MDO1	Nichicon, 1500µF 6.3V Aluminum Polymer Capacitor Radial, Can 9mOhm 2000 Hrs @ 105°C, PLG	View
PLG0E272MDO1TD	Nichicon, 2700µF 2.5V Aluminum Polymer Capacitor Radial, Can 8mOhm 2000 Hrs @ 105°C, PLG	View

PLG1C821MDO1

Part NumberPLG1C821MDO1
