PLT5BPH3013R7SNL
PLT5BPH3013R7SNL
Part Number PLT5BPH3013R7SNL Description CMC 2.2A 2LN 300OHM SMD AEC-Q200 Package / Case Vertical, 4 PC PadUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description 2 Line Common Mode Choke Surface Mount 300 Ohms @ 10MHz 2.2A DCR 11mOhm (Typ)
To learn about the specification of PLT5BPH3013R7SNL, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add PLT5BPH3013R7SNL with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of PLT5BPH3013R7SNL.
We are offering PLT5BPH3013R7SNL for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
PLT5BPH3013R7SNL - Product Attributes
Categories
Filters / Common Mode Chokes
Datasheet PLT5BPH Series Ref Sheet Standard Package 300 Manufacturer Murata Electronics North America Series PLT5BPH Packaging Tape & Reel (TR) Part Status Active Filter Type - Number of Lines 2 Impedance @ Frequency 300 Ohms @ 10MHz Current Rating (Max) 2.2A DC Resistance (DCR) (Max) 11mOhm (Typ) Voltage Rating - DC 80V Voltage Rating - AC - Operating Temperature -55°C ~ 150°C Ratings AEC-Q200 Approvals - Features - Mounting Type Surface Mount Size / Dimension 0.197" L x 0.197" W (5.00mm x 5.00mm) Height (Max) 0.197" (5.00mm) Package / Case Vertical, 4 PC Pad
