Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	PLV Series
Standard Package	1
Manufacturer	Nichicon
Series	PLV
Packaging	Cut Tape (CT)
Part Status	Active
Type	Polymer
Capacitance	56µF
Tolerance	±20%
Voltage - Rated	35V
ESR (Equivalent Series Resistance)	29mOhm
Lifetime @ Temp.	3000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Ratings	-
Applications	General Purpose
Ripple Current @ High Frequency	1.9A @ 100kHz
Lead Spacing	0.138" (3.50mm)
Size / Dimension	0.315" Dia (8.00mm)
Height - Seated (Max)	0.354" (9.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

PLV1J220MCL1	Nichicon, 22µF 63V Aluminum Polymer Capacitor Radial, Can 35mOhm 3000 Hrs @ 105°C, PLV	View
PLV1D221MDL1	Nichicon, 220µF 20V Aluminum Polymer Capacitor Radial, Can 25mOhm 3000 Hrs @ 105°C, PLV	View
PLV1C471MDL1	Nichicon, 470µF 16V Aluminum Polymer Capacitor Radial, Can 23mOhm 3000 Hrs @ 105°C, PLV	View
PLV1H680MDL1	Nichicon, 68µF 50V Aluminum Polymer Capacitor Radial, Can 28mOhm 3000 Hrs @ 105°C, PLV	View
PLV1K120MDL1TD	Nichicon, 12µF 80V Aluminum Polymer Capacitor Radial, Can 3000 Hrs @ 105°C, PLV	View
PLV1C221MCL1	Nichicon, 220µF 16V Aluminum Polymer Capacitor Radial, Can 26mOhm 3000 Hrs @ 105°C, PLV	View
PLV1E151MDL1TD	Nichicon, 150µF 25V Aluminum Polymer Capacitor Radial, Can 26mOhm 3000 Hrs @ 105°C, PLV	View
PLV1V560MCL1TD	Nichicon, 56µF 35V Aluminum Polymer Capacitor Radial, Can 29mOhm 3000 Hrs @ 105°C, PLV	View
PLV1H390MDL1	Nichicon, 39µF 50V Aluminum Polymer Capacitor Radial, Can 29mOhm 3000 Hrs @ 105°C, PLV	View
PLV1C271MDL1TD	Nichicon, 270µF 16V Aluminum Polymer Capacitor Radial, Can 24mOhm 3000 Hrs @ 105°C, PLV	View
PLV1E121MCL1TD	Nichicon, 120µF 25V Aluminum Polymer Capacitor Radial, Can 28mOhm 3000 Hrs @ 105°C, PLV	View
PLV1J470MDL1	Nichicon, 47µF 63V Aluminum Polymer Capacitor Radial, Can 29mOhm 3000 Hrs @ 105°C, PLV	View

PLV1V560MCL1TD

Part NumberPLV1V560MCL1TD
