SIT5156AICFK-25E0-16.369000X

Part NumberSIT5156AICFK-25E0-16.369000X

ManufacturerSiTIME

DescriptionMEMS OSC TCXO 16.3690MHZ SNWV

DatasheetSiT5156 Datasheet

Package / Case10-SMD, No Lead

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description16.369MHz TCXO Clipped Sine Wave Oscillator 2.5V Enable/Disable 10-SMD, No Lead

To learn about the specification of SIT5156AICFK-25E0-16.369000X, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SIT5156AICFK-25E0-16.369000X with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SIT5156AICFK-25E0-16.369000X.
We are offering SIT5156AICFK-25E0-16.369000X for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

SIT5156AICFK-25E0-16.369000X - Product Attributes

Categories	Crystals, Oscillators, Resonators / Oscillators
Datasheet	SiT5156 Datasheet
Standard Package	250
Manufacturer	SiTIME
Series	SiT5156, Elite Platform™
Packaging	Tape & Reel (TR)
Part Status	Active
Base Resonator	MEMS
Type	TCXO
Frequency	16.369MHz
Function	Enable/Disable
Output	Clipped Sine Wave
Voltage - Supply	2.5V
Frequency Stability	±0.5ppm
Absolute Pull Range (APR)	-
Operating Temperature	-40°C ~ 85°C
Spread Spectrum Bandwidth	-
Current - Supply (Max)	57mA
Ratings	-
Mounting Type	Surface Mount
Package / Case	10-SMD, No Lead
Size / Dimension	0.197" L x 0.126" W (5.00mm x 3.20mm)
Height - Seated (Max)	0.042" (1.06mm)
Current - Supply (Disable) (Max)	51mA
