STL110N10F7

STL110N10F7

Part NumberSTL110N10F7

ManufacturerSTMicroelectronics

DescriptionMOSFET N-CH 100V 21A PWRFLAT5X6

DatasheetSTL110N10F7

Package / Case8-PowerVDFN

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 100V 107A (Tc) 136W (Tc) Surface Mount PowerFlat™ (5x6)

To learn about the specification of STL110N10F7, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add STL110N10F7 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of STL110N10F7.
We are offering STL110N10F7 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

STL110N10F7 - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	STL110N10F7
Standard Package	3000
Manufacturer	STMicroelectronics
Series	DeepGATE™, STripFET™ VII
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	100V
Current - Continuous Drain (Id) @ 25°C	107A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	6mOhm @ 10A, 10V
Vgs(th) (Max) @ Id	4.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	72nC @ 10V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	5117pF @ 50V
FET Feature	-
Power Dissipation (Max)	136W (Tc)
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	PowerFlat™ (5x6)
Package / Case	8-PowerVDFN
