STTH1506TPI

Part NumberSTTH1506TPI

ManufacturerSTMicroelectronics

DescriptionDIODE ARRAY GP 600V 15A 3TOPI

DatasheetSTTH1506TPI

Package / CaseTOP-3 Insulated

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionDiode Array 1 Pair Series Connection Standard 600V 15A Through Hole TOP-3 Insulated

To learn about the specification of STTH1506TPI, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add STTH1506TPI with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of STTH1506TPI.
We are offering STTH1506TPI for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

STTH1506TPI - Product Attributes

Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Datasheet	STTH1506TPI
Standard Package	30
Manufacturer	STMicroelectronics
Series	-
Packaging	Tube
Part Status	Active
Diode Configuration	1 Pair Series Connection
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	600V
Current - Average Rectified (Io) (per Diode)	15A
Voltage - Forward (Vf) (Max) @ If	3.6V @ 15A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)	35ns
Current - Reverse Leakage @ Vr	20µA @ 600V
Operating Temperature - Junction	150°C (Max)
Mounting Type	Through Hole
Package / Case	TOP-3 Insulated
Supplier Device Package	TOP-3I
