SU10VD-20010


SU10VD-20010

Part NumberSU10VD-20010

Manufacturer

Description

Datasheet

Package / CaseVertical, 4 PC Pin

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

SU10VD-20010 - Product Attributes

Categories Filters / Common Mode Chokes
Datasheet
Standard Package700
ManufacturerKEMET
SeriesSU
PackagingBulk
Part StatusActive
Filter TypePower Line
Number of Lines2
Inductance @ Frequency10µH @ 1kHz
Current Rating (Max)2A
DC Resistance (DCR) (Max)100mOhm
Voltage Rating - DC-
Voltage Rating - AC250V
Operating Temperature-25°C ~ 120°C
Ratings-
Approvals-
Features-
Mounting TypeThrough Hole
Size / Dimension0.709" L x 0.630" W (18.00mm x 16.00mm)
Height (Max)0.787" (20.00mm)
Package / CaseVertical, 4 PC Pin
