SUD50N04-8M8P-4GE3
SUD50N04-8M8P-4GE3
Part Number SUD50N04-8M8P-4GE3
Description MOSFET N-CH 40V 14A TO-252
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Unit Price Request a Quote
Lead Time To be Confirmed
Detailed Description N-Channel 40V 14A (Ta), 50A (Tc) 3.1W (Ta), 48.1W (Tc) Surface Mount TO-252, (D-Pak)
To learn about the specification of SUD50N04-8M8P-4GE3, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SUD50N04-8M8P-4GE3 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SUD50N04-8M8P-4GE3.
We are offering SUD50N04-8M8P-4GE3 for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
SUD50N04-8M8P-4GE3 - Product Attributes
Categories
Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet SUD50N04-8M8P
Standard Package 2500
Manufacturer Vishay Siliconix
Series TrenchFET®
Packaging Tape & Reel (TR)
Part Status Active
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 40V
Current - Continuous Drain (Id) @ 25°C 14A (Ta), 50A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 8.8mOhm @ 20A, 10V
Vgs(th) (Max) @ Id 3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 56nC @ 10V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 2400pF @ 20V
FET Feature -
Power Dissipation (Max) 3.1W (Ta), 48.1W (Tc)
Operating Temperature -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Supplier Device Package TO-252, (D-Pak)
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
